NUZHUO High Quality Liquid Oxygen Plant Air Separation Plant Made In China

Short Description:

1. Air Compressor: Air is compressed at a low pressure of 5-7 bar (0.5-0.7mpa)

2. Pre Cooling System: Cooling the temperature of air to around 12 deg C.

3. Purification of Air By Purifier: Twin molecular Sieve driers

4. Cryogenic Cooling of Air by Expander: Turbo expander cools the temperature of    air below -165 to-170 deg C.

5. Separation of Liquid Air into Oxygen and Nitrogen by Air Separation Column

6. Liquid Oxygen/Nitrogen is stored in a Liquid Storage Tank


  • Brand: NUZHUO
  • Certification: CE, ISO9001, ISO13485, TUV, SGS Certificate Approved
  • After-Sale Service: Lifetime tech support & Dispatch Engineer & Video Meeting
  • Warranty: 1 Year, lifetime technology support
  • Salient Features: Nice Quality, Nice Price, Easy Operation, Easy Maintenance
  • Service: OEM & ODM Support
  • NUZHUO Supply: Oxygen concentrator, PSA oxygen generator, PSA nitrogen generator, Cryogenic ASU plant, Liquid Nitrogen & Oxygen Generator, Booster Compressor
  • Advantage : 20 Years manufacturing and exporting experience
  • Product Detail

    Company Profile

    FAQ

    Product Tags

    Liquid air separation: equipment for producing all of liquid.

    Technical Features: 1, Fast startup time; 2,Convenient storage and transportation; 3,The equipment is simple and easy to realize automatic production.

    Standard Model and Parameters:



    Model

    KDON-50/50

    KDON-80/160

    KDON-180/300

    KDON-260/500

    KDON-350/700

    KDON-550/1000

    KDON-750/1500

    KDONAr-1200/2000/30y

    O2 0utput (Nm3/h)

    50

    80

    180

    260

    350

    550

    750

    1200

    O2 Purity (%O2)

    ≥99.6

    ≥99.6

    ≥99.6

    ≥99.6

    ≥99.6

    ≥99.6

    ≥99.6

    ≥99.6

    N2 0utput (Nm3/h)

    50

    160

    300

    500

    700

    1000

    1500

    2000

    N2 Purity (PPm O2)

    9.5

    ≤10

    ≤10

    ≤10

    ≤10

    ≤10

    ≤10

    ≤10

    Liquid Argon Ouput

    ( Nm3/h)

         ——

    ——

    ——

    ——

    ——

    ——

    ——

    30

    Liquid Argon Purity

    ( Ppm O2 + PPm N2)

    ——

    ——

    ——

    ——

    ——

    ——

    ——

    ≤1.5ppmO2 + 4 p p mN2

    Liquid Argon Pressure

    ( MPa.A)

    ——

    ——

    ——

    ——

    ——

    ——

    ——

    0.2

    Consumption

    (Kwh/Nm3 O2)

    ≤1.3

    ≤0.85

    ≤0.68

    ≤0.68

    ≤0.65

    ≤0.65

    ≤0.63

    ≤0.55

    Occupied Area

    (m3)

    145

    150

    160

    180

    250

    420

    450

    800

    Technical Features



    Technical Features

    1). Fully automatic

    All systems are designed for unattended operation and automatic oxygen demand adjustment.

    2). lower space requirements

    The design and instrumentation allow for a very compact factory size, assembled on slides, and factory prefabricated.

    3). Quick Start

    Start-up time is only 5 minutes to obtain the required oxygen purity. So these devices can be turned on and off in response to changes in oxygen demand.

    4). High reliability

    Continuous stable operation with constant oxygen purity is very reliable. Factory availability is consistently better than 99%.

    5). Molecular sieve life

    The molecular sieve life is expected to be about 15 years, which is the entire life of the oxygen equipment. Therefore no replacement costs are required.

    6). adjustable

    By varying the flow, you can provide oxygen with the correct purity.



    Packing and delivery :

    orrect purity.

    Advantage

    We construct oxygen plant for cylinder filling with best materials and components. We customize the plants as per customer requirements and local conditions. We stand out in the industrial gas market we offer the best combination of cost and efficiency our systems. Being fully automated, the plants can run unattended and can also perform remote diagnostic troubleshooting.

    Precision designing increases efficiency and lowers power consumption thereby saving significant proportion of bills on operational and maintenance costs. Moreover, return on investment of our onsite oxygen systems is excellent allowing the customers to break even within two years.

    correct purity.

    FAQ :

    Q1. What are your strengths?

    We provide you not only technology-leading, stable and reliable, cost-effective equipment, but also solutions and after-sales service.

    Q2. Have your engineers participated in foreign projects?

    Yes, our engineers have more than 15 years of experience in this field and have been involved in the design, manufacture, installation and commissioning of equipment in Turkey, Egypt, Myanmar, etc.

    Q3. How can I get the exact price of the product?

    Please tell us your specific requirements and environmental data so that we can provide you with the most suitable products and solutions.


  • Previous:
  • Next:

  • Company Profile

    1. Full Experience: 20+ Years Manufacturing and Exporting Experience in ASU Field.

    2. Production Capability:100+ PSA Oxygen Plant Be Sold Per Month.
    3. Workshop Area: Our Factory Located in Tonglu District, Hangzhou, China, With 14000+ Square Meters, With 6 Production Lines, With 60Labors, With 3 Quality Inspectors, With 5 Excellent Engineers.
    4. Sales HQ Area: Our International trade depart With 25 Professional salesmen; With 1500+ Square Meters Area;
    5. After-sales Service: Online Technology Support & Video Meeting Support & Dispatch Engineer Support
    6. Warranty: 1 Year Guaranty Period, 1 Year Spare Parts With Factory Cost
    8. Our Advantage: Nice Quality! Nice Price! Nice Service!

    Certificate & NUZHUO

    Customers & NUZHUO

    合作案例

    Markets & NUZHUO

    customer map

    Q1: Are you a trading company or manufacturer?

    A: Firstly. we are a manufacturer, we have our own factory and engineers.
    Secondly, we have our own international trade teams to provide services for you.
    Thirdly, we provide the lifetime technology support and the best after-sale service.

    Q2: What is your term of payment?
    A: 30%T/T in advance and balance before shipment.
    B. 30% T/T in advance and Irrevocable L/C at Sight.
    C. Accept negotiation.
    Welcome to have a contact with our salesman: 0086-18069835230, Lyan.ji@hznuzhuo.com

    Q3: How long is your delivery time?


    A: Depending on what type of machine you are purchased. Cryogenic ASU, the delivery time is at least 3 months. Cryogenic liquid plant, the delivery time is at least 5 months. Welcome to have a contact with our salesman: 0086-18069835230, Lyan.ji@hznuzhuo.com



    Q4: What is your product quality assurance policy?
    A: We offer a warranty period of 1 year, free lifetime technology support.
    B. Accept negotiation.
    Welcome to have a contact with our salesman: 0086-18069835230, Lyan.ji@hznuzhuo.com

    Q5: Do you offer OEM/ODM service?
    A: Yes.
    Welcome to have a contact with our salesman: 0086-13516820594, Lowry.Ye@hznuzhuo.com
    Q6: Does your product used or new? RTS product or customized product?

    A:Our machine is new unit, and following your specific require to design and make it.
    Welcome to have a contact with our salesman: 0086-18069835230, Lyan.ji@hznuzhuo.com
