NUZHUO Cryogenic Air Separation Unit Liquid Nitrogen Plant Liquid Oxygen Machine Factory Price In competitive Price

Short Description:

Cryogenic air separation machine. If you need oxygen/nitrogen/argon both liquid and gas, we can produce different size, purity, capacity custimized

  • Brand: NUZHUO
  • Certification: CE, ISO9001, ISO13485, TUV, SGS Certificate Approved
  • After-Sale Service: Lifetime tech support & Dispatch Engineer & Video Meeting
  • Warranty: 1 Year, lifetime technology support
  • Salient Features: Nice Quality, Nice Price, Easy Operation, Easy Maintenance
  • Service: OEM & ODM Support
  • NUZHUO Supply: Oxygen concentrator, PSA oxygen generator, PSA nitrogen generator, Cryogenic ASU plant, Liquid Nitrogen & Oxygen Generator, Booster Compressor
  • Advantage : 20 Years manufacturing and exporting experience
  • Product Detail

    Company Profile


    Product Tags

    Product Name
    Cryogenic Liquid Oxygen Plant
    Model No.
    NZDON- 50/60/80/100 CUSTOMIZED
    Air compressor & Re- cooling system & Expander
    High purity Oxygen & Nitrogen & Argon production machine
    O2 0utput (Nm3/h)
    O2 Purity (%O2)
    N2 0utput (Nm3/h)
    N2 Purity (PPm O2)
    Liquid Argon Ouput
    ( Nm3/h)
    Liquid Argon Purity
    ( Ppm O2 + PPm N2)
    ≤1.5ppmO2 + 4 p p mN2
    Liquid Argon Pressure
    ( MPa.A)
    (Kwh/Nm3 O2)
    Occupied Area

    Product Advantages
    1.Simple installation and maintenance thanks to modular design and construction.
    2.Fully automated system for simple and reliable operation.
    3.Guaranteed availability of high-purity industrial gases.
    4.Guaranteed by the availability of product in liquid phase to be stored for use during any maintenance operations.
    5.Low energy consumption.
    6.Short time delivery.
    Application Fields
    Oxygen, nitrogen, argon and other rare gas produced by air separation unit are widely used in steel, chemical industry,refinery,glass, rubber, electronics, healthcare, food, metals, power generation and other industries.

    Product Specification

    1. Design principle of this plant is based on the different boiling point of each gas in the air. Air is compressed, precooled and got removal of H2O and CO2, then to be cooled in the main heat exchanger until it is liquified. After rectification,production oxygen and nitrogen can be collected.
    2. This plant is of MS purification of air with boosting turbine expander process. It is a common air separation plant, which adopts complete stuff filling and rectification for argon making.
    3. Raw air goes to air filter for removal of dust and mechanical impurity and enters air turbine compressor where air is compressed to 0.59MPaA. Then it goes into air precooling system, where air is cooled to 17 ℃. After that, it flows to 2 molecular sieve adsorbing tank, which are running in turn, to be got removal of H2O, CO2 and C2H2.

    * 1. After purified, air mixes with expanding reheated air. Then it is compressed by middle pressure compressor to be divided into2 streams. One part goes to main heat exchanger to be cooled to -260K, and sucked from the middle part of main heat exchanger to enter expansion turbine. Expanded air returns to main heat exchanger to be reheated, after that, it flows to air boosting compressor. The other part of air is boosted by high temperature expander, after cooling, it flows to the low temperature boosting expander. Then it goes to cold box to be cooled to ~170K. Part of it would still be cooled, and flows to bottom of lower column via heat exchanger. And other air is sucked to low tempt. expander. After expanded, it is divided into 2 parts. One part goes to the bottom of lower column for rectification, the rest returns to main heat exchanger, then it flows to air booster after being reheated.
    2. After primary rectification in lower column, liquid air and pure liquid nitrogen can be collected in lower column. Waste liquid nitrogen, liquid air and pure liquid nitrogen flows to upper column via liquid air and liquid nitrogen cooler. It is rectified in upper column again, after that, liquid oxygen of 99.6% purity can be collected at the bottom of upper column,
    and is delivered out of the cold box as production.
    3. Part of argon fraction in upper column is sucked to crude argon column. There are 2 parts of crude argon column. The reflux of second part is delivered to the top of first one via liquid pump as reflux. It is rectified in crude argon column to get 98.5% Ar. 2ppm O2 crude argon. Then it is delivered to the middle of pure argon column via evaporator. After rectification in pure argon column, (99.999%Ar) liquid argon can be collected at the bottom of pure argon column.
    4. Waste nitrogen from top of upper column flows out of the cold box to purifier as regenerative air, rest goes to cooling tower.
    5. Nitrogen from top of assistant column of upper column flows out of cold box as production via cooler and main heat exchanger. If no need nitrogen, then it could be delivered to water cooling tower. For cold capacity of water cooling tower is not sufficient, a chiller needs to be installed.
